Network variables
62
SCPTmaxSendTime / nciSndHrtBt
Definition:
Network config input SNVT_time_sec nciSndHrtBt
Explanation:
Provides the maximum send time for the variable nvoDrvSpeed.
Valid range:
0 .. 6553.5 sec (0.1 sec)
The value 0xFFFF represents invalid data.
Default value:
0 (disabled)
UCPTstopMode /
nciStopMode
Selects between coast and ramp stop.
UCPTstopLevel /
nciStopLevel
Stop level value in ramp stop mode.
UCPTpidGain /
nciPidGain
PID controller gain in percentage.
UCPTpidIntTime /
nciPIDIntTime
PID controller integration time in seconds.
UCPTpidDerTime /
nciPidDerTime
PID controller derivation time in seconds.
UCPTparValue /
nciParValue
Value input for the user selected parameter
nciParWrite.
UCPTparRead /
nciParRead
Chooses the parameter value to be read
from the drive.
UCPTparWrite /
nciParWrite
Defines the parameter value to be written to
the drive.
