Network variables
43
Network variables
Supported input network variables
The actual valid range of a network input variable can be smaller
than the one reported in this manual, depending of the drive
firmware. Typically the ACx550 discards the parameter changes, if
the value coming from the fieldbus is outside the range of the drive
parameter; ACS800 limits too large values to the highest value
allowed.
Name Description
NviDrvSpeedStpt Low-resolution speed set point.
NviDrvSpeedScale Scaling for nviDrvSpeedStpt.
NviResetFault Input to the motor to clear the fault status in
the drive.
NviEmergOverride Possibility to stop the motor in case of an
emergency.
NviDigOutput Controls the state for digital output 1-8.
NviDigOutput1 Controls the state for digital output 1.
NviDigOutput2 Controls the state for digital output 2.
NviExt1Ext2Ctrl Sets the control location that should be used
(Ext1/Ext2).
