Network variables
45
NviDrvSpeedScale
Definition:
Network input SNVT_lev_percent nviDrvSpeedScale
Explanation:
Provides scaling for nviDrvSpeedStpt. For example if
nviDrvSpeedStpt value is 100% and nviDrvSpeedScale value is
-150%, then the actual speed setpoint value is -150% meaning 1.5
times the nominal speed in reverse direction.
Valid range:
-163.84% .. 163.83% (0.005% or 50 ppm)
The value 0x7FFF represents invalid data.
Default value:
Defined by nciDrvSpdScale. This value will be adopted at
power-up and in case of not receiving an update within the
specified Receive Heartbeat time.
NviResetFault
Definition:
Network input SNVT_switch nviResetFault
Explanation:
Provides an input to the motor to clear the fault status in the drive.
Valid range:
On a transition from 0 to 1, this input network variable clears the
fault condition in the drive. Following a fault reset, this variable
should be set to '0' to enable the next reset fault.
State Value Command
0 0% Enable reset fault
1 100% Reset fault
