Fault tracing
73
Fault tracing
LED indications
The RLON-01 module is equipped with four diagnostic LEDs. The
description of the LEDs is presented below.
Name Colour Function
Host
indication
Green Lit - Link functions.
Red Lit - Link is lost permanently.
Flashing - Link is lost temporarily.
Service
Green Off - The module is configured and installed in a network.
Flashing - The module has an application but it is not yet
installed in a network.
Lit - The module is unconfigured and applicationless.
Indicates errors detected by the Neuron self-test routine.
Wink
Red Off - Normal state
Flashing - A wink command is received via the LonWorks
®
network.
Network
status
Green Lit - The module has been initialised correctly and is
working properly.
Off - The module is not powered.
Red Flashing - A receive heartbeat timeout has occurred.
Results in a network communication loss indication to the
drive.
Service
Wink
Network status
Host indication
