Network variables
57
NvoDigInput2
Definition:
Network output SNVT_switch nvoDigInput2
Explanation:
Indicates the status of Digital Input 2 (DI2).
Valid range:
A value of 0xFF on nvoDigInput2.state represents invalid data.
NvoAnlgInput
Note: For ACx550 only.
Definition:
Network output SNVT_lev_percent nvoAnlgInput
Explanation:
Contains the status of Analog Input.
Valid range:
-163.84% .. 163.83% (0.005% or 50 ppm)
A value of 0x7FFF represents invalid data.
State Value Command
00%low
1 100% high
