Network variables
46
Default value:
The module will power-up in the 'Enable Reset Fault' state.
NviEmergOverride
Definition:
Network input SNVT_hvac_emerg nviEmergOverride (HVAC
Emergency Mode)
Explanation:
Provides the possibility to stop the motor in case of an emergency.
Valid range:
Default value:
EMERG_NORMAL
Setting Function
EMERG_NORMAL No emergency mode, motor control
enabled.
EMERG_PRESSURIZE Not in use
EMERG_DEPRESSURIZE Not in use
EMERG_PURGE Not in use
EMERG_SHUTDOWN Emergency shutdown mode. Stops
motor.
EMERG_FIRE Not in use
EMERG_NUL Not in use
