Network variables
47
NviDigOutput
Note: The number of digital inputs varies between the drive types.
Definition:
Network input SNVT_state nviDigOutput
Explanation:
Controls the state for digital output 1-8.
Valid range:
Default value:
0
bit0 Sets Digital Output 1
bit1 Sets Digital Output 2
bit2 Sets Digital Output 3
bit3 Sets Digital Output 4
bit4 Sets Digital Output 5
bit5 Sets Digital Output 6
bit6 Sets Digital Output 7
bit7 Sets Digital Output 8
bit8-15 Unused
