![ABB RLON-01 [28/82] Note these parameters become visible in the drive only after the rlon 01 has been configured on the network side](/img/pdf.png)
ABB RLON-01 [28/82] Note these parameters become visible in the drive only after the rlon 01 has been configured on the network side
![ABB RLON-01 [28/82] Note these parameters become visible in the drive only after the rlon 01 has been configured on the network side](/views2/1556908/page28/bg1c.png)
Programming
28
Note: These parameters become visible in the drive only after the
RLON-01 has been configured on the network side.
RLON-01 information parameters
Fieldbus
par. no.
Parameter name Description
1 MODULE TYPE Type of the module (LonWorks)
2 NODE STATE State of the RLON-01
3-8 NEURON ID [5...0] Neuron
®
chip ID
9 NODE ADRESS 1 ID of the node within this subnet
10 NODE SUBNET 1 Subnet to which the node belongs
11-16 DOMAIN ID 1 [4...0] Domain ID in a LonWorks network
17 NODE ADRESS 2 ID of the node within this subnet
19-24 DOMAIN ID 2 [4...0] ID in a LonWorks network
25 XMIT ERRORS Number of CRC errors
26 TRANS TIMEOUTS Number of transmission failures
