ABB RLON-01 [25/82] Earthing the lonworks cable screens
![ABB RLON-01 [25/82] Earthing the lonworks cable screens](/views2/1556908/page25/bg19.png)
Electrical installation
25
Earthing the LONWORKS
®
cable screens
The LONWORKS
®
cable screen can be directly earthed at one
station only. At other stations the screen should be earthed via an
RC filter.
Different bus terminations
T1
52.5 ohm termination at one of the nodes in one bus
segment
T2
105 ohm termination at both ends of the line
NO
No termination
SHF
Net B
Net A
X1
RLON-01
SHF
X1
SHF
RLON-01RLON-01
4 5
X1
Net B
Net A
4 5
Net B
Net A
4 5
105 Ω
105 Ω
Network cable connection for bus topology.
