Network variables
60
Valid range:
A value of 0xFF on nvoExt1Ext2Stat represents invalid data.
NvoLocRemStat
Definition:
Network output SNVT_switch nvoLocRemStat
Explanation:
This output variable shows if the drive is in Local or Remote
control mode.
Valid range:
A value of 0xFF on nvoLocRemStat represents invalid data.
NvoLastFault
Definition:
Network output SNVT_switch nvoLastFault
Explanation:
This output variable shows the latest malfunction code that has
occurred.
Valid range:
As parameter 82 in Profile Server
State Value Command
0 0% Ext1 Selected
1 100% Ext2 Selected
State Value Command
0 0% Drive is controlled locally
1 100% Drive is controlled from the network
