Network variables
61
Supported network configuration properties
All configuration properties are defined as configuration network
variables in this product. Some network management tools will
show these variables as SCPT/UCPT configuration properties and
some as network configuration variables. The difference in the
network management tools only affects the presentation of the
variables but not their functionality.
Name Description
SCPTmaxSendTime /
nciSndHrtBt
Maximum send time for the variable
nvoDrvSpeed.
SCPTmaxRcvTime /
nciRcvHrtBt
Defines the maximum allowed update
interval for input network variables
nviDrvSpeedStpt and nviDrvSpdScale.
SCPTminSendTime /
nciMinOutTm
Defines the minimum wait time before the
network output variables can be propagated
(resent).
SCPTnomRPM /
nciNmlSpeed
Sets the nominal motor speed.
SCPTnomFreq /
nciNmlFreq
Sets the nominal frequency of the motor.
SCPTminSetpoint /
nciMinSpeed
Defines the minimum speed of the motor as
a percentage of the nominal speed defined
by the Nominal Speed (nciNmlSpeed)
configuration value.
SCPTmaxSetpoint /
nciMaxSpeed
Defines the maximum motor speed.
SCPTrampUpTm /
nciRampUpTm
Sets the ramp up time of the drive.
SCPTrampDownTm /
nciRampDownTm
Sets the ramp down time of the drive.
SCPTlocation /
nciLocation
Physical location of the node.
SCPTdefScale /
nciDrvSpdScl
Default value for nviDrvSpeedScale
