Network variables
44
NviDrvSpeedStpt
Definition:
Network input SNVT_switch nviDrvSpeedStpt
Explanation:
Provides a low-resolution speed set point. The speed set point is
the result of multiplication of nviDrvSpeedStpt and
nviDrvSpeedScale. For example if the value of the
nviDrvSpeedStpt is 100% and the value of the nviDrvSpeedScale
is -150%, the actual speed setpoint value is -150% meaning 1.5
times nominal speed in reverse direction.
Valid range:
Default value:
The default value is AUTO (state = 0xFF). The value will be
adapted at power-up and in case of not receiving an update within
the specified Receive Heartbeat time. This input network variable
may use the Receive Heartbeat function if the Receive Heartbeat
function is set up for use. The actual drive speed also depends on
nviDrvSpeedScale.
This value is transmitted immediately when its value has changed
significantly, but no faster than the Minimum Send Time
(nciMinOutTm) configuration value, if used.
Additionally, this network variable will also be transmitted as a
heartbeat output on a regular basis as specified by the Maximum
Send Time (nciSndHrtBt) configuration value.
State Value Equivalent
percentage
Requested
speed
0 Not used Not used STOPPED
1 0 0% 0%
1 1 to 100 1 to 100.0% 1 to 100.0%
0xFF Not used Not used AUTO (invalid)
