Drive parameter settings
33
Drive parameter settings
ACx550 parameter settings
Parameter Setting Function
9904 MOTOR CTRL
MODE
Motor control mode
SPEED; SCALAR
Initialises RLON-01 operation
mode.
9907 MOTOR NOM
FREQ*
Motor nominal
frequency
Initialises the nciNmlFreq value.
9908 MOTOR NOM
SPEED*
Motor nominal speed Initialises the nciNmlSpeed value.
This value corresponds to
nviSpeedStpt value 100% (of
nominal speed or frequency).
1001 EXT1
COMMANDS
COMM Enables network control of the
drive.
1003 DIRECTION REQUEST Enables change of direction.
1102 EXT1/EXT2 SEL COMM Enables the change of external
control location via nviExt1Ext2Sel
1103 REF1 SELECT COMM Enables setting the reference 1 via
network.
1106 REF2 SELECT COMM Enables setting the reference 1 via
network.
1401 RELAY
OUTPUT1
COMM Enables control of relay output 1 via
nviDigOutput and nviDigOutput1.
1402 RELAY
OUTPUT2
COMM Enables control of relay output 2 via
nviDigOutput and nviDigOutput2.
1403 RELAY
OUTPUT3
COMM Enables control of relay output 3 via
nviDigOutput and nviDigOutput1.
1601 RUN ENABLE COMM Enables the run enable command
via the network.
