Drive parameter settings
34
*If one of the drive parameter values marked with * not using the
corresponding configuration network variable is changed, the
RLON-01 needs to be re-initialised in order to update it's value.
For example, if the stop mode parameter is changed with the
control panel, the RLON-01 needs to be either rebooted or
temporarily disabled for the RLON-01 to read the updated value
from the drive. The same applies if one of the marked parameters
using the nciParValue configuration parameter is changed.
1604 FAULT RESET
SEL
COMM Enables the fault reset command
via the network.
2001 MINIMUM
SPEED*
Minimum motor
speed.
Initialises nciMinSpeed value.
2002 MAXIMUM
SPEED*
Maximum motor
speed.
Initialises nciMaxSpeed value.
2007 MINIMUM
FREQ*
Minimum output
frequency.
Initialises nciMinSpeed value.
2008 MAXIMUM
FREQ*
Maximum output
frequency.
Initialises nciMaxSpeed value.
2202 ACCELER
TIME 1
Acceleration time Initialises nciRampUpTm value.
2203 DECELER
TIME 1
Deceleration time Initialises nciRampDownTm value.
4001 GAIN* PID gain Initialises nciPidGain value.
4002 INTEGRATION
TIME*
PID integration time Initialises nciPidIntTime value.
4003 DERIVATION
TIME*
PID derivation time Initialises nciPidDerTime value.
9802 COMM PROT
SEL
EXT FBA Enables fieldbus communication
with the drive.
Parameter Setting Function
