ABB RLON-01 [56/82] Explanation
![ABB RLON-01 [56/82] Explanation](/views2/1556908/page56/bg38.png)
Network variables
56
NvoEmergOvrStat
Definition:
Network output SNVT_hvac_emerg nvoEmergOvrStat
Explanation:
Feedback for the nviEmergOverride
Valid range:
A value of EMERG_NUL represents invalid data.
NvoDigInput1
Definition:
Network output SNVT_switch nvoDigInput1
Explanation:
Indicates the status of Digital Input 1 (DI1).
Valid range:
A value of 0xFF on nvoDigInput1.state represents invalid data.
Value Function
EMERG_NORMAL No emergency mode, motor control ena-
bled
EMERG_SHUTDOWN Emergency shutdown mode. Stops motor.
State Value Command
00%low
1 100% high
