Verto 52G607 [10/56] Detailed safety regulations
![Verto 52G607 [10/56] Detailed safety regulations](/views2/1569827/page10/bga.png)
10
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
ELECTRIC PLANER
52G607
CAUTION: BEFORE USING THE POWER TOOL READ THIS MANUAL
CAREFULLY AND KEEP IT FOR FUTURE REFERENCE.
DETAILED SAFETY REGULATIONS
SPECIAL CONDITIONS REGARDING SAFETY OF ELECTRIC PLANER
OPERATION
• Before connecting the planer to mains socket make sure the supply
voltage matches the voltage on the rating plate of the tool.
• Connect the planer only to electrical system equipped with residual
current circuit breaker that will cut the power o when earth
leakage current exceeds 30 mA in less than 30 ms.
• Use only sharp cutting parts.
• After the work has been nished and before putting the planer
away wait until rotating parts stop completely.
• Use hearing protection measures when working with planer.
• When using the planer hold it rmly with both hands.
• Power cord of the planer must be on the safe side, where there is no
danger of accidental damage by operating power tool.
• Before starting operation ensure there are no metal objects, such as
nails or screws, in the processed material.
• Do not put ngers into dust outlet hole. Clean the outlet with a
piece of wood.
• Fix processed material to prevent it from slipping.
CAUTION! This device is designed to operate indoors.
The design is assumed to be safe, protection measures and
additional safety systems are used, nevertheless there is always
a small risk of operational injuries.
CONSTRUCTION AND USE
Planer is a hand-held power tool with insulation class II. The tool is
driven by single-phase commutator motor. Planer is designed for
processing wooden surfaces.
Range of use covers repair and building works, woodworking and any
work from the scope of individual, amateur activities (tinkering).
Use the power tool according to the manufacturer’s instructions
only.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the
drawing pages of this manual.
1. Knob for planing depth adjustment
2. Switch
3. Switch lock button
4. Drive belt cover
5. Dust extraction outlet
6. Front footplate
7. Planing depth scale
8. Parallel guide position locking wheel
9. Parallel guide
10. Support
11. Support locking knob
12. Deep planing guide
13. Locking knob for deep planing guide
14. Guide handle
15. Fixing screws
16. Blade
17. Head
18. V groove
21. Removable shield
* Dierences may appear between the product and drawing.
GB
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY/SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Dust bag - 1 pce
2. Flat spanner - 1 pce
3. Hexagonal key - 1 pce
4. Parallel guide + support - 1 set
5. Deep planing guide - 1 pce
6. Screw + knobs - 1 set
PREPARATION FOR OPERATION
DUST EXTRACTION
Planer is equipped with dust extraction system, which prevents
excessive deposition of dust in the work place. When operating the
planer for a long time on the surfaces that produce harmful dust,
the planer must be connected to external dust suction device.
DUST BAG INSTALLATION
Equipment of the planer includes dust bag to maintain the processed
surface clean.
• Slide the dust bag fastening onto dust extraction outlet (5) (g. C).
• Deinstallation of the dust bag is similar to installation, only the
sequence of actions is reversed.
Empty the dust bag on a regular basis, this will ensure ecient
operation of the planer. Emptying the bag when it is half-full is
recommended.
PARALLEL GUIDE INSTALLATION
• Place the support (10) in the guide (on the left side) in the planer
body and secure with support locking knob (11) (included).
• Use the supplied screw and locking wheel (8) to attach parallel
guide (9) to the support (10) (g. D).
• Set parallel guide to appropriate planing width.
Parallel guide bar should be pointed downwards.
INSTALLATION OF DEEP PLANING GUIDE
• Place the deep planing guide (12) in the guide (on the right side) in
the planer body and secure with the locking knob for deep planing
guide (13) (included) (g. E).
• Use the scale on the deep planing guide (12) to set planing depth.
