Daikin EWADC12C-XL [142/304] Legend
![Daikin EWAD820C-PL [142/304] Legend](/views2/1693821/page142/bg8e.png)
General Outline ESIE10-01
1–136 Part 1 – System Outline
3
11
4
5
1.36.32 Legend
Item Description
A.C. Alarm Control
C1 Power Factor Correction
C2 Power Factor Correction
C3 Power Factor Correction
C.C.1 Control Compressor (Siemens)
C.C.2 Control Compressor (Siemens)
C.C.3 Control Compressor (Siemens)
CP-1 Condenser Pressure Transducer Cir. 1
CP-2 Condenser Pressure Transducer Cir. 2
CP-3 Condenser Pressure Transducer Cir. 2
DRV1 Speedtrol 1
DRV2 Speedtrol 1
DRV3 Speedtrol 1
DT-1 Discharge Temp. Sensor Cir. 1 (PT1000)
DT-2 Discharge Temp. Sensor Cir. 2 (PT1000)
DT-3 Discharge Temp. Sensor Cir. 2 (PT1000)
EEWT Evaporator Entering Water Temperature
EEXV1 Expansion Compressor 1
EEXV2 Expansion Compressor 1
EEXV3 Expansion Compressor 1
ELWT Evaporator Leaving Water Temperature
EP-1 Evaporator Pressure Transducer Cir. 1
EP-2 Evaporator Pressure Transducer Cir. 2
EP-3 Evaporator Pressure Transducer Cir. 2
ESV-1 Economizer Solenoid Valve Cir. 1
ESV-2 Economizer Solenoid Valve Cir. 1
ESV-3 Economizer Solenoid Valve Cir. 1
EXV-1 Electronic Expansion Valve
EXV-2 Electronic Expansion Valve
EXV-3 Electronic Expansion Valve
F0 Compressor Fuses
F1 Compressor Fuses
F2 Compressor Fuses
F3 Compressor Fuses
F9 Pump Fuses 1
F59 Auxiliary Circuit Fuse
F62 Protection Fuse
F70 Thermal Relay Pump 1
F80 Thermal Relay Pump 2
F90 Termostat (Closed > 30°C)
F9A Pump Fuses 2
F100 Fan Fuses
F112 Phase Volt Monitor
F116 Evaporator Flow Switch
F120 Auxiliary Protection Fuses
F200 Fan Fuses
F300 Fan Fuses
F5-1 Thermal Relay
F5-2 Thermal Relay
F5-3 Thermal Relay
F112A Under/Overvoltage Control
F13-1 Mech. High Pressure Switch Cir. 1
