ESIE10-01 General Outline
Part 1 – System Outline 1–57
3
1
4
5
Notes Cc (cooling capacity) – Pi (unit power input) – ELWT (evaporator leaving water temperature – Δt 5°C).
Data are referred to 0,0176 m
2
°C/kW evaporator fouling factor.
EWAD~C-SR
Size
ELWT
(°C)
Condenser Inlet Air Temperature (°C)
25 30 35 40 42 44 46
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
620
4 632 182 602 197 567 212 543 221 527 228 500 238 472 249
5 651 186 619 200 584 216 560 225 543 232 516 243 487 254
6 670 189 637 204 602 219 577 230 560 236 532 247 502 258
7 689 192 656 207 619 223 594 234 577 241 548 251 508 258
8 709 196 674 211 636 227 611 238 593 245 564 256 510 256
9 727 199 693 215 654 231 628 242 610 249 581 261 511 254
10 747 203 712 219 672 235 645 246 626 254 597 265 515 252
11 766 206 730 222 690 240 662 250 643 258 613 270 515 249
12 785 210 749 226 708 244 680 255 660 262 629 274 518 246
13 805 213 767 230 725 248 697 259 677 267 646 279 520 244
14 825 217 786 234 743 252 715 264 695 272 662 284 526 243
15 845 221 805 238 761 257 732 268 712 276 671 285 528 239
720
4 716 217 693 237 664 259 642 273 625 283 597 299 495 271
5 735 221 711 241 681 263 658 278 641 288 605 299 496 268
6 754 225 730 245 698 268 674 283 655 292 615 300 499 266
7 773 229 748 250 715 272 691 287 665 293 625 300 502 263
8 793 233 766 254 732 277 707 292 673 294 635 300 506 261
9 812 237 785 258 749 282 724 297 682 295 644 300 507 258
10 832 241 803 263 767 287 734 299 692 296 655 301 511 255
11 852 245 822 267 784 292 744 300 701 296 660 298 511 251
12 871 250 841 272 802 297 752 300 712 298 665 295 516 250
13 892 254 860 277 820 302 762 301 716 297 667 289 518 246
14 912 259 879 282 835 305 773 303 715 293 671 286 523 245
15 932 263 898 287 846 307 782 304 719 291 675 281 523 241
790
4 803 251 773 274 733 298 705 314 683 325 629 329 487 280
5 824 256 793 279 752 304 723 320 688 324 634 326 491 277
6 845 261 812 284 771 309 740 326 688 321 635 319 490 272
7 866 266 832 289 789 315 758 332 692 319 643 317 494 269
8 887 270 852 295 808 321 763 331 695 317 646 312 496 265
9 908 276 872 300 827 327 767 329 697 314 649 306 499 262
10 929 281 892 306 845 333 765 325 699 311 656 303 506 262
11 950 286 912 311 864 339 768 322 705 310 657 296 508 258
12 972 291 932 317 873 340 770 319 705 305 663 293 508 253
13 994 297 952 323 876 338 776 318 710 303 668 289 515 253
14 1,015 302 972 329 879 336 776 314 709 298 673 285 515 248
15 1,037 308 992 335 881 333 782 313 713 296 677 281 521 247
