ESIE10-01 General Outline
Part 1 – System Outline 1–53
3
1
4
5
1.22 Electrical Specifications: EWAD~C-PR
Electrical
specifications
The table below contains the electrical specifications
Model EWAD~C-PR
820 890 980 C11 C12 C13 C14
Power Supply Phase 3
Frequency Hz 50
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Unit Maximum starting current A 635.2 672 672 908.2 953.8 1010.2 1015.4
Nominal running current cooling A 376 416 461 505 554 614 671
Maximum running current A 493 539 585 647 704 773 842
Maximum current for wires siz-
ing
A 542 593 643 712 774 851 927
Fans Nominal running current in cool-
ing
A 47 47 47 52 52 57 62
Compressor Phase No. 3
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Maximum running current A 223
+223
223
+269
269
+269
269
+326
326
+326
390
+326
390
+390
Starting Method Wye - Delta type (Y -Δ)
