ESIE10-01 The Digital Controller
Part 2 – Functional Description 2–15
3
2
4
5
1
View/Set Unit AWM Setup (view/set unit)
Status/Settings > Apply Changes R/W
Set-Up > DHCP R/W
Temperatures > Actual IP Address R
Date/Time/Schedules > Actual Mask R
Power Conservation > Actual Gateway R
LON Setup > Given IP Address R/W
BACnet IP Setup > Given Mask R/W
BACnet MSTP Setup > Given Gateway R/W
Modbus Setup > AWM BSP R
AWM Setup >
Design Conditions (view/set)
Design Conditions > Evap Entering Water Temp @ R
Alarm Limits > Evap Leaving Water Temp @ R
Menu Password > Alarm Limits (view/set unit)
Low Pressure Hold Setpoint R
Low Pressure Unload Setpoint R
View/Set Circuit >
Menu Password (view/set)
Status/Settings > Password Disable R/W
Compressor >
Status/Settings (view/set)
Time Until Restart Status Circuit 1
Compressor 1 Cycle Time R Circuit Status R
Compressor 2 Cycle Time R Circuit Mode R/W
Compressor 3 Cycle Time R Circuit Capacity R
Compressor 4 Cycle Time R Status Circuit 2 >
Status Circuit 3 >
Scheduled Maintenance Status Circuit 4 >
Next Maintenance Month/Year R/W
Service Support Reference R Compressor (view/set circuit)
Compressor 1 Circuit 1
Alarms > Run Hours R
Alarm Active > Number Of Starts R
Alarm Log >
Alarm Active (Alarms)
About This Chiller Active Alarm 1 R
Model Number R ... R
G.O. Number R Active Alarm n R
Unit Serial Number R Acknowledge All R/W
Starter Model Number(s) R
Starter Serial Number(s) R Alarm Log (Alarms)
Firmware Version R Alarm Entry 1 R
Application Version R ... R
Application GUID R Alarm Entry 25 R
HMI GUID R
OBH GUID R
