General Outline ESIE10-01
1–62 Part 1 – System Outline
3
11
4
5
C13
4 1,311 333 1,275 362 1,233 392 1,182 425 1,100 468 1,066 483 999 487
5 1,352 338 1,314 368 1,271 398 1,218 431 1,133 475 1,099 490 1,007 482
6 1,393 343 1,354 373 1,310 404 1,255 438 1,168 482 1,133 498 1,013 476
7 1,434 348 1,395 379 1,349 411 1,292 444 1,202 489 1,166 505 1,018 470
8 1,476 354 1,435 385 1,389 417 1,330 451 1,237 496 1,183 506 1,022 462
9 1,518 359 1,477 391 1,428 423 1,368 458 1,273 504 1,190 501 1,034 459
10 1,562 365 1,519 397 1,469 430 1,406 465 1,309 511 1,196 495 1,035 451
11 1,606 371 1,561 403 1,509 437 1,445 472 1,346 519 1,201 489 1,046 447
12 1,650 377 1,605 410 1,551 443 1,484 479 1,363 519 1,204 481 1,055 442
13 1,694 383 1,648 416 1,593 450 1,524 487 1,369 514 1,217 478 1,052 432
14 1,739 389 1,692 423 1,636 457 1,564 494 1,374 508 1,217 469 1,059 426
15 1,784 395 1,735 429 1,677 465 1,605 502 1,388 505 1,228 465 1,065 420
C14
4 1,369 355 1,335 387 1,299 420 1,253 456 1,179 504 1,148 521 1,113 540
5 1,407 360 1,373 392 1,335 426 1,289 462 1,213 510 1,182 528 1,146 546
6 1,445 364 1,410 397 1,372 431 1,325 468 1,247 517 1,215 535 1,180 554
7 1,484 369 1,449 403 1,409 437 1,361 474 1,282 524 1,249 542 1,213 561
8 1,523 374 1,487 408 1,447 443 1,397 480 1,316 530 1,284 549 1,247 568
9 1,562 379 1,526 413 1,485 448 1,434 486 1,351 537 1,318 556 1,275 572
10 1,602 384 1,565 418 1,523 454 1,470 492 1,387 544 1,352 563 1,297 575
11 1,643 389 1,605 424 1,561 460 1,508 499 1,422 551 1,387 570 1,322 578
12 1,684 394 1,645 429 1,601 466 1,545 505 1,458 558 1,423 577 1,346 581
13 1,726 399 1,686 435 1,640 472 1,583 512 1,494 565 1,458 584 1,371 584
14 1,768 404 1,727 440 1,680 478 1,622 518 1,530 572 1,484 587 1,394 586
15 1,810 409 1,769 446 1,720 484 1,660 525 1,567 579 1,509 591 1,415 587
C15
4 1,484 385 1,446 419 1,403 455 1,349 493 1,262 544 1,226 563 1,186 583
5 1,526 390 1,488 425 1,443 461 1,388 500 1,299 552 1,262 571 1,221 591
6 1,569 395 1,530 431 1,485 468 1,428 507 1,336 559 1,299 579 1,257 599
7 1,612 401 1,572 437 1,526 474 1,468 514 1,374 567 1,336 587 1,293 607
8 1,655 406 1,614 443 1,567 481 1,508 521 1,412 575 1,373 595 1,312 606
9 1,699 412 1,657 449 1,609 487 1,548 528 1,450 583 1,411 603 1,324 601
10 1,744 418 1,701 455 1,651 494 1,588 535 1,489 591 1,449 611 1,340 598
11 1,789 424 1,745 462 1,694 501 1,629 543 1,528 599 1,487 619 1,363 598
12 1,834 430 1,789 468 1,737 508 1,671 550 1,567 607 1,512 622 1,378 594
13 1,880 436 1,834 474 1,780 515 1,712 558 1,606 615 1,530 620 1,393 590
14 1,926 442 1,879 481 1,824 522 1,754 566 1,646 624 1,548 617 1,407 586
15 1,973 448 1,925 488 1,867 529 1,796 573 1,686 632 1,571 617 1,410 576
C16
4 1,555 409 1,515 445 1,469 483 1,410 524 1,316 579 1,278 600 1,235 621
5 1,599 415 1,558 452 1,511 490 1,451 532 1,354 587 1,314 608 1,271 629
6 1,642 420 1,601 458 1,553 497 1,491 539 1,392 596 1,352 616 1,307 638
7 1,686 426 1,644 464 1,596 504 1,533 547 1,431 604 1,390 625 1,344 647
8 1,731 432 1,688 471 1,638 511 1,574 555 1,470 612 1,428 633 1,345 640
9 1,776 438 1,732 477 1,680 518 1,615 562 1,510 621 1,466 642 1,353 637
10 1,821 444 1,776 484 1,723 525 1,656 570 1,550 630 1,505 651 1,360 633
11 1,868 451 1,822 491 1,767 533 1,698 578 1,589 638 1,545 660 1,365 628
12 1,915 457 1,867 498 1,811 540 1,740 586 1,629 647 1,564 661 1,369 622
13 1,962 463 1,913 505 1,855 548 1,782 594 1,668 656 1,572 658 1,371 615
14 2,010 470 1,960 512 1,900 555 1,825 602 1,708 665 1,578 654 1,383 613
15 2,058 477 2,007 519 1,945 563 1,868 611 1,749 674 1,583 648 1,382 604
Size
ELWT
(°C)
Condenser Inlet Air Temperature (°C)
25 30 35 40 46 48 50
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
