30 – English
TECHNICAL DATA
1155355-93 Rev.4 2014-11-24
Technical data
Note 1: Noise emissions in the environment measured as sound power (L
WA
) in conformity with EC directive 2000/14/
EC.
Note 2: Equivalent sound pressure level, according to ISO 22868, is calculated as the time-weighted energy total for
different sound pressure levels under various working conditions. Typical statistical dispersion for equivalent sound
pressure level is a standard deviation of 1 dB (A).
Note 3: Equivalent vibration level, according to ISO 22867, is calculated as the time-weighted energy total for vibration
levels under various working conditions. Reported data for equivalent vibration level has a typical statistical dispersion
(standard deviation) of 1 m/s
2
.
435 II 435e II 440 II 440e II
Engine
Cylinder displacement, cm
3
40,9 40,9 40,9 40,9
Cylinder bore, mm 41 41 41 41
Stroke, mm 31 31 31 31
Idle speed, rpm 2900 2900 2900 2900
Power, kW/ rpm 1,6/9000 1,6/9000 1,8/9000 1,8/9000
Ignition system
Spark plug
NGK BPMR 7A/
Champion RCJ 7Y
NGK BPMR 7A/
Champion RCJ 7Y
NGK BPMR 7A/
Champion RCJ 7Y
NGK BPMR 7A/
Champion RCJ 7Y
Electrode gap, mm 0,5 0,5 0,5 0,5
Fuel and lubrication system
Fuel tank capacity, litre 0,37 0,37 0,37 0,37
Oil pump capacity at 9,000 rpm, ml/min 13 13 13 13
Oil tank capacity, litre 0,25 0,25 0,25 0,25
Type of oil pump Automatic Automatic Automatic Automatic
Weight
Chain saw without bar or chain, empty
tanks, kg
4,2 4,4 4,2 4,4
Noise emissions (see note 1)
Sound power level, measured dB (A) 112 112 113 113
Sound power level, guaranteed L
WA
dB
(A)
114 114 114 114
Sound levels (see note 2)
Equivalent sound pressure level at the
operator’s ear, dB(A)
102 102 102 102
Equivalent vibration levels, a
hveq
(see note 3)
Front handle, m/s
2
2,5 2,5 2,5 2,5
Rear handle, m/s
2
3,2 3,2 3,2 3,2
Chain/bar
Standard bar length, inch/cm 13"/33 13"/33 13/33 13"/33
Recommended bar lengths, inch/cm 13-18/33-45 13-18/33-45 13-18/33-45 13-18/33-45
Usable cutting length, inch/cm 12-17/31-43 12-17/31-43 12-17/31-43 12-17/31-43
Pitch, inch/mm 0,325/8,25 0,325/8,25 0,325/8,25 0,325/8,25
Thickness of drive links, inch/mm 0,050/1,3 0,050/1,3 0,050/1,3 0,050/1,3
Type of drive sprocket/number of teeth Spur/7 Spur/7 Spur/7 Spur/7
Chain speed at 133% of maximum
engine power speed, m/s.
23,1 23,1 23,1 23,1
