Editing Programs Page 23
Storing Programs
Storing is done identically regardless if you are saving an edited Program or if you are saving from Manual
mode.
Saving a Program will permanently overwrite an existing Program. Be careful so that you don’t acciden-
tally erase a Program you’d like to keep! However, there is no danger of permanently losing the Factory
Programs in RAM locations 01-40, since these are backed up as ROM Performances (see page 106).
1. Press the Store button.
The display flashes.
2. Use the Program Up/Down button to select a Program number.
You can play the now selected Program, in this mode, to decide if you want to replace it or not.
Only Program numbers up to 40 in internal memory Bank can be used for saving!. If you try to save in
higher program numbers, nothing will happen!
3. If you change your mind at this point, press the Program Slot you want to return to or press the Manual button
to return to Manual Mode.
4. If you decide to go ahead with overwriting the existing Program, press Store again.
The display stops flashing to indicate the Program has been saved.
Copying Programs
Copying Programs between memory slots is just a variation on Storing:
1. Select the Program you want to copy.
2. Press Store.
3. Use the Program Up/Down button to specify the memory location you want to copy the program to.
4. Press Store again.
