Shift Functions Page 59
Prog/Ctrl
This is used for setting how Program Change and Control Change MIDI messages should be handled,
and for turning the Arpeggio MIDI Out feature on and off.
These parameters are Global for the entire instrument, that is, the settings are valid for all Performances
and Programs.
To switch between the three different parameters, press the Prog/Ctrl button. The left character in the
display switches between “P” (Program), “C” (Control) and “A” (Arpeggio).
For the two first parameters (“P” and “C”) you use the Program Select buttons to switch between “–” and
“1”. The “–” value means that no data of that type is transmitted or received. “1” means that type of data
is both transmitted and received. The Arpeggio MIDI Out feature requires some explanation:
Arpeggio and MIDI Out
If you want to, generated arpeggios can be sent out as MIDI notes. This makes it possible to arpeggiate
chords on connected synthesizers and sound modules, and to record arpeggios in a sequencer. You ac-
tivate it using the Prg. Ctrl. menu:
1. Press the Prg/Ctrl button to select parameter.
The left character in the display switches between “P” (Program), “C” (Control) and “A” (Arpeggio).
2. Use the Program Up and Down buttons to switch between “–” and “1”.
▼ For the Program and Control parameters, the “1” setting means that the respective MIDI data is transmit-
ted and received by the Nord Lead, while the “–” setting means that it is not.
▼ For the Arpeggio parameter, the “1” setting means that generated arpeggios can be sent out as MIDI
notes. This makes it possible to arpeggiate chords on connected synthesizers and sound modules, and
to record arpeggios in a sequencer.
With the “–” setting, the chord you play on the keyboard is sent to MIDI Out, regardless of whether the
Nord Lead arpeggio is activated or not.
Be sure to turn the Arpeggio MIDI Out feature off if you are using Nord Lead in Local Off mode and/or
in a “Thru-loop” with a sequencer, other MIDI instruments etc! Under such conditions, the Arpeggio MIDI
Out feature will either prevent the instrument from sounding at all, or cause a MIDI feedback loop.
MIDI Channel
Program Slot MIDI Channel
To set the MIDI Channel that a certain Program slot receives and transmits on, proceed as follows:
1. Hold down “Shift” and press “MIDI Ch”.
2. The display shows the MIDI Channel for the active Program slot.
3. Select the Program slot you want to make settings for.
The Program slot’s LED flashes.
