MIDI Implementation Page 93
▼ If Message Type = 0 (Edit Buffer), the Message Specification can be 0 to 3, corresponding to Patch Slot
buttons A to D.
▼ If Message Type = 1 to 4, then the Message Specification (99 to 108) corresponds to the Percussion Kit
locations (P0 to P9).
Patch Dump Request
This message is used for requesting the Nord Lead to transmit one Patch or Percussion Kit Dump Mes-
sage. The Message Type and Message Specification are used to specify which Patch should be transmit-
ted.
This message is never transmitted from the Nord Lead.
▼ If Message Type = 10 (Edit Buffer), the Message Specification can be $00 to $03, corresponding to Patch
Slot buttons A to D.
Byte (Hex) Byte (Decimal) Description
$F0 240 System Exclusive
$33 51 Manufacturer ID (clavia)
<Device ID> = Global MIDI Channel. 0 to 15 ($0-$F).
$04 4 Model ID for Nord Lead
$00 to $04 0 to 4 Message Type specifies the Bank. 0=Edit Buffer, 1 to
4=Bank 1 to 4
$10 to $13 or $63-$6C 16 to 19 or 99 to
108
Message Specification specifies the exact memory loca-
tion, see below.
<Patch Data 1> Patch data for eight percussion sounds. See page 96.
<Patch Data 2>
<Patch Data 3>
:
<Patch Data 1056>
$F7 247 End Of Exclusive
Byte (Hex) Byte (Decimal) Description
$F0 240 System Exclusive
$33 51 Manufacturer ID (clavia)
<Device ID> = Global MIDI Channel. 0 to 15 ($0-$F).
$04 4 Model ID for Nord Lead
$A to $E 10 to 14 Message Type specifies the Bank. $A=Edit Buffer, $B to
$E=Bank 1 to 4
$00 to $03 or
$00-$6C
0 to 3 or 0 to 108 Message Specification specifies the exact memory location,
see below.
$F7 247 End Of Exclusive
