Page 96 MIDI Implementation
Patch and Performance Data Formats
In the Patch and Performance Dump Messages, the Data Bytes contain the actual Patch/Performance set-
tings.
▼ All parameters are in 8 bit format, 2s complement (=signed). Each Byte is Nybbleized and coded into two
MIDI bytes, with the low Nybble transmitted first.
▼ A Patch contains 66 parameters, which means the data block of a Patch Dump is transmitted in 132 (66*2)
Bytes. See the “Patch Dump Format” table, below.
▼ A Performance consists of five blocks. The first four blocks contains the four Patches (A to D) This block
is 528 MIDI Bytes (4*66*2). After this follows 136 (68*2) of data for parameters local to the Performance.
See the “Performance Data Format” table, on page 97.
Patch Dump Format
Size Offset Name Min Max Comment
1 0 osc2pitch 0 120 middle=60
1 1 osc2pitchfine 0 127
1 2 mix 0 127
1 3 cutoff 0 127
1 4 resonance 0 127
1 5 filterenvamt 0 127
1 6 pw 0 127
1 7 fmdepth 0 127
1 8 filterenvattack 0 127
1 9 filterenvdecay 0 127
1 10 filterenvsustain 0 127
1 11 filterenvrelease 0 127
1 12 ampenvattack 0 127
1 13 ampenvdecay 0 127
1 14 ampenvsustain 0 127
1 15 ampenvrelease 0 127
1 16 portamento 0 127
1 17 gain 0 127
1 18 modenvattack 0 127
1 19 modenvdecay 0 127
1 20 modenvlevel 0 127 middle=64
1 21 lfo1rate 0 127
1 22 lfo1level 0 127
1 23 lfo2rate 0 127
1 24 arprange 0 127
1 25 osc2pitch_sens -128 127 velocity/morf sens
1 26 osc2pitchfine_sens -128 127 0=OFF
1 27 mix_sens -128 127
1 28 cutoff_sens -128 127
1 29 resonance_sens -128 127
1 30 filterenvamt_sens -128 127
1 31 pw_sens -128 127
1 32 fmdepth_sens -128 127
1 33 filterenvattack_sens -128 127
1 34 filterenvdecay_sens -128 127
1 35 filterenvsustain_sens -128 127
1 36 filterenvrelease_sens -128 127
1 37 ampenvattack_sens -128 127
1 38 ampenvdecay_sens -128 127
1 39 ampenvsustain_sens -128 127
1 40 ampenvrelease_sens -128 127
