MIDI Implementation Page 97
For Percussion Kit Sys Ex Dumps, the above parameters will be repeated eight times, once for each sound
in the Percussion Kit.
Performance Data Format
1 41 portamento_sens -128 127
1 42 gain_sens -128 127
1 43 modenvattack_sens -128 127
1 44 modenvdecay_sens -128 127
1 45 modenvlevel_sens -128 127
1 46 lfo1rate_sens -128 127
1 47 lfo1level_sens -128 127
1 48 lfo2rate_sens -128 127
1 49 arprange_sens -128 127
1 50 osc1waveform 0 2
1 51 osc2waveform 0 3 3=noise
1 52 sync 0 1
1 53 filtertype 0 4
1 54 osc2kbdtrack 0 1
1 55 filterkbdtrack 0 1
1 56 lfo1wave 0 2
1 57 lfo1dest 0 3
1 58 voicemode 0 2
1 59 modwheeldest 0 4
1 60 unison 0 1
1 61 modenvdest 0 2
1 62 auto 0 1
1 63 filtervel 0 1
1 64 octshift 0 4
1 65 lfo2dest/arpmode 0 4
Size Offset Name Min Max Comment
264 0 "performance_patch [A,B,C,D]" see PATCH data format
4 264 "midichan [A,B,C,D]" 0 15
4 268 "lfo1sync [A,B,C,D]" 0 7
4 272 "lfo2sync [A,B,C,D]" 0 7
4 276 "filterenvtrig [A,B,C,D]" 0 1
4 280 "filterenvtrigmidichan [A,B,C,D]" 0 15
4 284 "filterenvtrignotenr [A,B,C,D]" 23 127 23=off
4 288 "ampenvtrig [A,B,C,D]" 0 1
4 292 "ampenvtrigmidichan [A,B,C,D]" 0 15
4 296 "ampenvtrignotenr [A,B,C,D]" 23 127 23=off
4 300 "morftrig [A,B,C,D]" 0 1
4 304 "morftrigmidichan [A,B,C,D]" 0 15
4 308 "morftrignotenr [A,B,C,D]" 23 127 23=off
1 312 bendrange 0 8
1 313 unisondetune 0 8
1 314 outmode 0 3
1 315 globalmidichan 0 15 not received!!!
1 316 midiprogchange 0 1 not received!!!
1 317 midicntrl 0 1 not received!!!
1 318 mastertune -99 99 not received!!!
1 319 pedaltype 0 2 not received!!!
1 320 localcontrol 0 1 not received!!!
1 321 Keyboard Octave Shift 0 4 not received!!!
1 322 selected_channel 0 3
1 323 Arpeggio MIDI Out 0 1 not received!!!
4 324 "channel_actived [A,B,C,D]" 0 1
Size Offset Name Min Max Comment
