Shift Functions Page 63
To set which MIDI Channel and possibly which MIDI note number to use for triggering, proceed as fol-
lows:
1. Activate the function.
In other words, set the display to “F.1”.
2. Press Store.
The display shows the MIDI Channel currently used. Set the value with the Up/Down buttons.
3. Press Store again.
The Displays shows which MIDI Note number is currently used. The numbers start at C0 (MIDI note
number 24), and a dot between the figures indicates a sharp (#). For example, “F.3” means F#3. “Middle
C” is indicated as “C3”.
The value “– –” means that note number is ignored, that is all notes on the set MIDI Channel will be used
for triggering. This value is found below all the “number values”.
Guidelines for Using Filter Envelope Triggering
▼ If you have notes transmitted from your sequencer that you want to use only for triggering the envelope,
make sure the MIDI Channel you use for this function is not used by any of the Program slots
▼ Please note that if the Velocity function in the Filter section is activated, the velocities of the incoming
MIDI notes are routed to Filter Envelope amount. This allows you to adjust the timbre of the sound with
the velocity of the incoming MIDI notes.
An Example of Filter Envelope Triggering
1. Select a Program for slot A, that plays a “stable sound with infinite sustain, for example a “string” or “pad”
sound.
2. Lower the Filter Cutoff to 0.
3. Raise the Filter Envelope amount and adjust the Filter envelope so that the sound has a short, snappy charac-
ter.
4. Hold down Shift and press MIDI Ch. Set the MIDI Channel for slot A to 1.
5. Press each of the other Program slot buttons and set them to MIDI Channel 16.
This is just to make sure they do not get used in this example.
6. Hold down Shift and press Special.
7. Press the Special button until the left digit in the display is “F”.
8. Make sure Program Slot A is selected. Otherwise press its button.
9. Use the Up/Down buttons to set the value to “1” (“on”).
10. Press Store. Use the Up/Down buttons to select MIDI Channel “2”.
11. Press Store again and adjust to “– –” (any MIDI note number).
12. Press Store again.
13. Make sure all other Special functions are turned off for this slot.
