Page 92 MIDI Implementation
▼ If the Sys Ex data for a single Patch is sent upon receiving a Patch Dump Request message, either the
Program Location or the Edit Buffer will be stored, depending on the Message Type byte in the Request
message. This will also determine where the Patch will be placed when it is sent back to a Nord Lead.
▼ If Message Type = 0 (Edit Buffer), the Message Specification can be 0 to 3, corresponding to Patch Slot
buttons A to D.
▼ If Message Type = 1 to 4, then the Message Specification (00 to 98) corresponds to the Program Number
within the Bank (01 to 99).
Percussion Kit Patch Dump
This message contains all settings in a Percussion Kit. It is transmitted from the Nord Lead in one of two
cases:
▼ When a Patch Dump is initiated from the front panel and a Percussion Kit is selected.
▼ When a valid Patch Dump Request message has been received, specifying a Percussion Kit location or
an Edit Buffer containing a Percussion Kit.
Percussion Kit Patch Dump messages will also be sent if the “Dump All” command is used.
This message should be sent to the Nord Lead when you want to replace a Percussion Kit currently in the
instrument, with a new one. When it comes to the location of the received Percussion Kit Dumps, the
same rules apply as when receiving regular Program Dumps. Just remember that the internal Percussion
Kit locations in the Nord Lead cannot be overwritten.
Byte (Hex) Byte (Decimal) Description
$F0 240 System Exclusive
$33 51 Manufacturer ID (clavia)
<Device ID> = Global MIDI Channel. 0 to 15 ($0-$F).
$04 4 Model ID for Nord Lead
$00 to $04 0 to 4 Message Type specifies the Bank. 0=Edit Buffer, 1 to
4=Bank 1 to 4
$00 to $03 or $00-$62 0 to 3 or 0 to 98 Message Specification specifies the exact memory loca-
tion, see below.
<Patch Data 1> See page 96.
<Patch Data 2>
<Patch Data 3>
:
<Patch Data 132>
$F7 247 End Of Exclusive
