MIDI Implementation Page 95
Performance Dump Request
This message is used for requesting the Nord Lead to transmit one Performance Dump Message. The Mes-
sage Type and Message Specification are used to specify which Performance should be transmitted.
This message is never transmitted from the Nord Lead.
▼ If Message Type = 40 (Edit Buffer), the Message Specification should always 0.
▼ If Message Type = 41 or 42, then the Message Specification (00 to 99) corresponds to the Performance
Number (A0 to L9).
All Controllers Request
This message instructs the Nord Lead to send all current Controller values for a specified Slot (see page
70). The message is never transmitted from the Nord Lead.
Byte (Hex) Byte (Decimal) Description
$F0 240 System Exclusive
$33 51 Manufacturer ID (clavia)
<Device ID> = Global MIDI Channel. 0 to 15 ($0-$F).
$04 4 Model ID for Nord Lead
$28 or $29 40 to 41 Message Type specifies Performance Edit Buffer (40) or
the PCMCIA card Performance Bank. (41).
$00 or $00-$63 0 or 0 to 99 Message Specification specifies the Performance number,
see below.
$F7 247 End Of Exclusive
Byte (Hex) Byte (Decimal) Description
$F0 240 System Exclusive
$33 51 Manufacturer ID (clavia)
<Device ID> = Global MIDI Channel. 0 to 15 ($0-$F).
$04 4 Model ID for Nord Lead
$14 20 Message Type specifies All Controllers Request.
$00-$03 0 to 3 Message Specification specifies the Program Slot.
$F7 247 End Of Exclusive
