Page 66 Shift Functions
System
Under this menu you will find three different functions, labelled “P”, “b”, and “U”.
To select one of the functions, hold down Shift and press the System. Then press the System button re-
peatedly until the left digit in the display shows the desired letter.
Pedal (P)
This is used to set how a connected pedal should be used. See page 17 for details.
This parameter is Global for the entire instrument, that is, the setting is valid for all Performances and
Programs.
Pitch Bend Range (b)
This allows you to set the range of the pitch stick, in semitones. The value is also used to set what effect
incoming pitch bend messages should have on the pitch.
The table below shows you how many semi-tones each value in the display represents.
This parameter is “global” for all Program slots. However, it is saved with a Performance.
Unison Detune (U)
This allows you to set how far detuned the voices should be when you have Unison activated. For more
info on Unison, see page 53.
This parameter is “global” for all Program slots. However, it is saved with a Performance.
Setting Range in semitones Setting Range in semitones
1 ±26±10
2 ±37±12
3 ±48±24
4 ±59±48
5 ±7
