Page 90 MIDI Implementation
In addition to the above, following controllers are used:
▼ The Modulation wheel transmits and receives Controller 1.
▼ If the Pedal input is used with an expression pedal, this is transmitted and received as Controller 11.
▼ If the Pedal input is used for sustain, this is transmitted as Controller 64 (Damper Pedal)
▼ Bank Select messages (Controller 0 and 32) are received.
Modulation Envelope Amount 29 Undefined
Osc 1 Waveform 30 Undefined
Osc 2 Waveform 31 Undefined
Osc 2 Semitones 78 Sound Controller 9
Osc 2 Fine Tune 33 LSB for Controller 1
Oscillator FM Depth 70 Sound Controller 1 (Sound Variation)
Osc 2 Keyboard Tracking 34 LSB for Controller 2
Oscillator Pulse Width 79 Sound Controller 10
Oscillator Sync 35 LSB for Controller 3
Oscillator Mix 8 Balance
Amplifier Envelope Attack 73 Sound Controller 4 (Attack)
Amplifier Envelope Decay 36 LSB for Controller 4
Amplifier Envelope Sustain 37 LSB for Controller 5
Amplifier Envelope Release 72 Sound Controller 3 (Release)
Filter Envelope Attack 38 LSB for Controller 6
Filter Envelope Decay 39 LSB for Controller 7
Filter Envelope Sustain 40 LSB for Controller 8
Filter Envelope Release 41 LSB for Controller 9
Filter Mode 44 LSB for Controller 12
Filter Cutoff 74 Sound Controller 2 (Timbre)
Filter Resonance 42 LSB for Controller 10
Filter Envelope Amount 43 LSB for Controller 11
Filter Velocity 45 LSB for Controller 13
Filter Keyboard Track 46 LSB for Controller 14
Nord Lead Parameter MIDI Controller # MIDI Controller Name
