![Kurzweil PC2 [109/170] The envelope menu percussion parameters](/img/pdf.png)
Kurzweil PC2 [109/170] The envelope menu percussion parameters
![Kurzweil PC2 [109/170] The envelope menu percussion parameters](/views2/2008899/page109/bg6d.png)
Descriptions of Parameters
KB3 Editor Parameters
5-29
NoteAttack
Controls the attack characteristic of KB3 notes.
Normal
Smoothed attack.
Hard
Instant attack with audible click, in addition to any amount of key click speciÞed with the
Keyclick and KeyclickVol parameters (you might want to set Keyclick to Off when you use this
setting).
PercHard
Hard attack level for percussion only; notes without percussion use a normal attack.
NoteRelease
Controls the release characteristic of notes.
The Envelope Menu: Percussion Parameters
There are four possible combinations of percussion effects. The following table lists these
combinations, and indicates which set of parameters corresponds to each combination.
For each combination, there are three parameters:
Level
Sets the absolute level of the percussion effect.
Decay
Sets the decay rate of the percussion effectÑthat is, how long it takes to fade to silence.
Volume Adjust (Vol Adj)
Adjusts the amplitude of the organ relative to the amplitude of the percussion effect.
Normal
Smoothed release.
Hard
Instant release with audible click.
Combination of Effects
Corresponding
Parameter Group
Loud and Fast Ld/Fast
Loud and Slow Ld/Slow
Soft and Fast Sft/Fast
Soft and Slow Sft/Slow
