Kurzweil PC2 [158/170] Pc2 programs and controller assignments
![Kurzweil PC2 [158/170] Pc2 programs and controller assignments](/views2/2008899/page158/bg9e.png)
C-16
PC2 Programs and Controller Assignments
Programs and Controllers
ID 101
Program Name Elec 12 String
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Envelope Control
SW1 Octave Shift
SW2 FX Vib/Chor On/Off
SW3 Layer Disable
SW4 Arp On/Off
SW5 Enable Leslie
MW Leslie Rate Switch
Breath/CCPed2 Tremolo
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
FtSw4 ArpLatch
ID 102
Program Name 335 VelSw Slide
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Attack Control
Slider D Decay Control
SW1 Octave Shift
SW2 Filter Env Control
SW3 Layer Switch
SW4 Arp On/Off
SW5 Enable Slide Layer
MW Vibrato
Breath/CCPed2 Vibrato
Ribbon Pitch Bend
CCPed1 Expression
FtSw2 Sostenuto
FtSw3 Envelope Control
ID 103
Program Name Rock Gtr Lead
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre (Dist)
Slider D Timbre (Tone)
SW1 Octave Shift
SW2 Disable FB Layer
SW4 Arp On/Off
SW5 Feedback in 5ths
MW Vibrato
Mpress Feedback Amount
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Release Control
ID 104
Program Name Round and Wound
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LoPass Freq (Cut)
Slider D Attack Control
SW1 Octave Shift
SW2 Impact
SW4 Arp On/Off
SW5 Layer Enable(Ride)
MW Vibrato
Mpress Vibrato
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 105
Program Name Punch Bass
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LoPass Freq
Slider D Attack Control
SW1 Octave Shift
SW2 Layer Disable
SW4 Arp On/Off
SW5 "LoPass Res, Freq"
MW Vibrato
Mpress Vibrato
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 106
Program Name Two Finger Bass
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LoPass Freq (Cut)
SW1 Octave Shift
SW2 Impact
SW4 Arp On/Off
SW5 Impact
MW Vibrato
Mpress Vibrato
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
