C-10
PC2 Programs and Controller Assignments
Programs and Controllers
ID 55
Program Name Pipe Organ
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Layer XFade
Slider D Layer XFade
SW1 Octave Shift
SW4 Arp On/Off
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 56
Program Name Big Brass
Slider C LoPass Freq
Slider D Attack Control
SW2 Layer Switch
SW5 Layer Switch
MW Vibrato Depth
Mpress Swell Env & Pitch
Breath/CCPed2 LoPass Freq
CCPed2 LoPass Freq
ID 57
Program Name Saxes/Trumpets
Slider C LoPass Freq
Slider D Attack Control
SW2 Layer Switch
SW3 Layer Switch
SW5 Layer Switch
MW Vibrato Depth
Mpress Swell Env & Pitch
Breath/CCPed2 LoPass Freq
CCPed2 LoPass Freq
ID 58
Program Name Split Sections
Slider C LoPass Freq
Slider D Attack Control
SW2 Layer Switch
SW5 Layer Switch
MW Vibrato Depth
Mpress Swell Env & Pitch
Breath/CCPed2 Timbre
CCPed2 Timbre
ID 59
Program Name Broadway Brass
Slider C LoPass Freq
Slider D Attack Control
SW5 Layer Switch
MW Vibrato Depth
Mpress Swell Env & Pitch
Breath/CCPed2 LoPass Freq
ID 60
Program Name Trombones
Slider C Timbre
Slider D Attack Control
SW5 Layer Switch
MW Vibrato Depth
Mpress Swell Env & Pitch
Breath/CCPed2 LoPass Freq
CCPed2 LoPass Freq
ID 61
Program Name The Two Tenors
Slider C LoPass Freq
Slider D Attack Control
SW2 Layer Switch
SW5 Layer Switch
MW Vibrato Depth
Mpress Swell Env & Pitch
Breath/CCPed2 LoPass Freq
CCPed2 LoPass Freq
ID 62
Program Name Solo Tenor Sax
Slider C LoPass Freq
Slider D Attack Control
MW Vibrato Depth
Mpress Vibrato Depth
ID 63
Program Name Empyre Brass
Slider C LoPass Envelope
SW2 Layer Switch
SW3 Layer Switch
SW5 Layer Switch
MW Vibrato Depth
Mpress Swell Envelope
ID 64
Program Name Lyrical Strings
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Brightness
SW1 Octave Shift
SW4 Arp On/Off
SW5 Envelope
MW Attack Switch
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
