C-14
PC2 Programs and Controller Assignments
Programs and Controllers
ID 89
Program Name Crypt
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Timbre
SW1 Octave Shift
SW2 Release Control
SW4 Arp On/Off
SW5 Vibrato Rate Env
MW "Vibr, Pan/Fltr LFO"
Mpress "Vibr, Pan/Fltr LFO"
Breath/CCPed2 Pan LFO Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
ID 90
Program Name Meteor Strings
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LoPass Freq
Slider D LoPass Resonance
SW1 Octave Shift
SW2 Release Control
SW3 Attack Control
SW4 Arp On/Off
SW5 Vibrato Rate Env
MW "Vibrato, Trem Depth"
Mpress Brightness
Breath/CCPed2 LoPass Freq
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
ID 91
Program Name Orch Pad
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Filter Freq
Slider D Filter LFO Rate
SW1 Octave Shift
SW2 Release Control
SW3 Layer Switch
SW4 Arp On/Off
SW5 Attack Control
MW Vibrato
Mpress Horn Layer Swell
Breath/CCPed2 Horn Layer Swell
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
ID 92
Program Name Slo Syn Orch
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C """Chiff"" Level"
Slider D Env Control
SW1 Octave Shift
SW4 Arp On/Off
SW5 Layer Disable
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
ID 93
Program Name Analogy
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LoPass Freq
Slider D LP Res & Release
SW2 Attack Control
SW4 Arp On/Off
SW5 Layer Enable
MW "Vibrato Rate, Depth"
Mpress Swell
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
ID 94
Program Name Paddy LaBelle
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LoPass Freq
Slider D LoPass Resonance
SW1 Octave Shift
SW2 Release Control
SW4 Arp On/Off
SW5 Attack Control
MW Filter LFO Depth
Mpress Swell
Breath/CCPed2 Swell
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
