![Kurzweil PC2 [126/170] Parameter reference](/views2/2008899/page126/bg7e.png)
B-4
Reference
Parameter Reference
Continuous
controllers:
Ribbons
Ribbons have
three common
parameters,
called the
Spring
Parameter
Subgroup
The ribbon
controllers also
have the six
basic
parameters.
Ribbon Sect Large, 3 Sect. Large
Spring
Parameters
Spring Switch Off, On On
Ribbon Mode Absolute, Relative Relative
Spring Pos 0–127 64
Ribbon 1 basic
parameters
As indicated in Basic Parameter Group
Ribbon 2 spring
parameters
As indicated in Spring Parameter Subgroup
Ribbon 2 basic
parameters
As indicated in Basic Parameter Group
Ribbon 3 spring
parameters
As indicated in Spring Parameter Subgroup
Ribbon 3 Basic
parameters
As indicated in Basic Parameter Group
Switch
controllers
All switch
controllers have
the same seven
parameters,
called the
Switch Control
Parameter
Group
Button SW1
SwType
On Ctrl
On Value
Off Ctrl
Off Value
Entry State
Exit State
Momentary, Toggle (default Momentary)
Any control source or destination (default None)
None; 0–127 (default None)
Any control source or destination (default None)
None; 0–127 (default None)
None, Off, On (default None)
None, Off, On (default None)
Button SW2
Button SW3
Button SW4
Button SW5
SwitchPdl 1
SwitchPdl 2
SwitchPdl 3
Arpeggiator
Arp Active Off, On Off
Key range
Low C-1 to G9 G 9
Hi C-1 to G9 C-1
Zone Enable Off, On On
Latch Mode Keys, OverPlay, Arpeg, Add, Auto, Pedals
Play Order
Played, Up, Down, Up & Down, Up & Down Rpt, Random,
Shuffle, Walk
Played
Beats
4th Notes, 8th Notes, 8th Trips, 16th Notes, 16th Trips, 32nd
Notes, 32nd Trips
4th Notes
Initial Tempo 20–300 BPM 120 BPM
Duration 1–100% 100%
Vel Mode Fixed, Played, Last, Pressure, Ctrl 117 Played
Fixed Vel 1–127 100
Note Shift -12 to 12 0
Shift Limit 0–88 24
Limit Opt
Stop, Reset, UniPolar, BiPolar, Flt Reset, Flt Unipolar,
Flt Bipolar
UniPolar
Glissando Off, On Off
Parameter
Group
Subgroup
(if any)
Parameter Range of Values Default
