PC2 Programs and Controller Assignments
Programs and Controllers
C-7
ID 37
Program Name Celestial Comet
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Treble Cut
Slider D Trem/Vib Rate
SW1 Octave Shift
SW2 Release Control
SW4 Arp On/Off
SW5 Switch Layers
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 38
Program Name DYN Comper
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LoPass Freq
Slider D Resonance
SW1 Octave Shift
SW2 Octave Drop
SW4 Arp On/Off
SW5 Impact
MW "Vibrato Rate, Depth"
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 39
Program Name Ruth Buzzy
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LoPass Freq Cut
Slider D Tremolo+Rate
SW1 Octave Shift
SW2 Resonance Boost
SW4 Arp On/Off
SW5 Decay Control
MW Vibrato
Mpress Vibrato
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 40
Program Name Clav Classic
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Bass Level
Slider D HiPass LFO Rate
SW1 Octave Shift
SW2 Disable Release
SW4 Arp On/Off
SW5 Layer Switch
MW HiPass LFO Depth
Ribbon Pitch Bend
CCPed1 Expression
CCPed2 HiPass LFO Depth
FtSw1 Sustain
FtSw2 Sostenuto
ID 41
Program Name Touch Clav
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Impact
SW1 Octave Shift
SW4 Arp On/Off
SW5 Layer Switch
MW BandPass LFO Rate
Mpress Timbre
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 42
Program Name Dual Wah Clav
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Bandpass Width
Slider D LFO2 Rate
SW1 Octave Shift
SW4 Arp On/Off
SW5 LFO => MW
MW Bandpass Freq(SW5)
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
