B-18
Reference
PC2 Effects and Effects Parameters
Rotary Speaker
ID Effect Param1 Param2 Param3 Param4
390 VibChor+Rotary1 Vibr/Chor Low Rate High Rate HiResonate
391 VibChor+Rotary2 Vibr/Chor Low Rate High Rate Roto InOut
392 VC+Dist+Rotary1 Vibr/Chor Low Rate High Rate Dist Drive
393 VC+Dist+Rotary2 Vibr/Chor Low Rate High Rate Dist Drive
394 VC+Dist+Rotary3 Vibr/Chor Low Rate High Rate Dist Drive
395 VC+Tube+Rotary1 Vibr/Chor Low Rate High Rate Tube Drive
396 VC+Tube+Rotary2 Vibr/Chor Low Rate High Rate Tube Drive
