Reference
Parameter Reference
B-7
KB3: Timbre
WheelVolMap Equal, Bright, Mellow, Junky
OrganMap Equal, Peck’s, Bob’s, Eric’s
Chor/Vib Vib1, Vib2, Vib3, Chor1, Chor2, Chor3
DrawbarMode Preset, Live
Drawbars 1–9 0–8
DrawbarSteps Smooth, Normal
PreampResp On, Off
Leakage -96 dB–0.0 dB
Amp -96 dB to +48 dB
KB3: Envelope
Keyclick Off, On
KeyclickVol -96 dB–0.0 dB
NoteAttack Normal, Hard, PercHard
NoteRelease Normal, Hard
Perc Ld/Fast
Level
Decay
Vol Adj
0.0 dB–24.0 dB
0.01 s—5.10s
-12.0 dB–12.0 dB
Perc Ld/Slow
Perc Sft/Fast
Perc Sft/Slow
Perc Pitch
Low Harm Drawbar1–Drawbar9
High Harm Drawbar1–Drawbar9
Steal Bar None, Drawbar1–Drawbar9
KB3: LFO Rotor Effects
Low Rate -10.00 Hz–10.00 Hz
Low Adjust -10.00 Hz–10.00 Hz
High Rate -10.00 Hz–10.00 Hz
High Adjust -10.00 Hz–10.00 Hz
Parameter
Group
Subgroup
(if any)
Parameter Range of Values Default
