Reference
MIDI Controllers
B-9
MIDI Controllers
Special Controllers
The controllers in the following table are not MIDI Controllers. The numerals indicate the
buttonpad entries that select the corresponding controllers.
None
0 Bank MSB 1 Bank LSB 2 Sustain 3 DataInc
4 Mod Whel 5 6 Port Switch 7 DataDec
8 Breath 9 10 Sosten 11 NRg LBS
12 13 14 Soft 15 NRg MSB
16 Foot Control 17 18 Legato 19 Rg LSB
20 Port Time 21 22 Hold2 23 Rg MSB
24 Data MSB 25 Data LSB 26 SndCtl1 27
28 Volume 29 30 SndCtl2 31
32 Balance 33 34 SndCtl3 35
36 37 38 SndCtl4 39
40 Pan 41 42 SndCtl5 43
44 Expression 45 46 SndCtl6 47
48 EfxCt 1 49 50 SndCtl7 51
52 EfxCt 2 53 54 SndCtl8 55
56 57 58 SndCtl9 59
60 AuxBnd2 61 62 SndCt10 63
64 Gen 1 65 66 Gen 5 67
68 Gen 2 69 70 Gen 6 71
72 Gen 3 73 74 Gen 7 75
76 Gen 4 77 78 Gen 8 79
80 81 82 PortCtl 83 ArpOn
84 AuxBnd1 MSB 85 86 87 ArpVel
88 89 90 91 Latch2
92 93 94 95 Latch1
96 97 98 99 SndOff
100 101 102 103 RstCtl
104 105 106 107 LclCtl
108 109 110 FXBWet 111 NtsOff
112 113 114 FXABWet 115 OmniOf
116 117 118 FXAWet 119 OmniOn
120 121 122 FXRoute 123 MonoOn
124 125 126 Ef5 Dpt 127 PolyOn
128 Pitch Bend 133 Tempo 138 Goto Prog 143 Seq Stop
129 Rev Bnd 134 Key Number 139 Setup Inc 144 Seq Cont
130 Pitch Up 135 Key Veloc 140 Setup Dec 145 Trans Up
131 Pitch Down 136 Prog Inc 141 Goto Setup 146 Trans Down
132 Pressure 137 Prog Dec 142 Seq Start
