Kurzweil PC2 [146/170] Pc2 programs and controller assignments
![Kurzweil PC2 [146/170] Pc2 programs and controller assignments](/views2/2008899/page146/bg92.png)
C-4
PC2 Programs and Controller Assignments
Programs and Controllers
ID 19
Program Name Hard E Pno
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Tremolo Rate
SW1 Octave Shift
SW2 Enable Thump
SW4 Arp On/Off
SW5 Impact
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Pedal
ID 20
Program Name E Piano PF
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Tremolo Rate
SW1 Octave Shift
SW2 Disable release
SW4 Arp On/Off
SW5 Disable Layer
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
CCPed2 Timbre
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Pedal
ID 21
Program Name Dyno E Pno
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Hi Freq Cut
Slider D Tremolo Rate
SW1 Octave Shift
SW2 Fast Decay
SW4 Arp On/Off
SW5 Impact
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
CCPed2 LoPass Freq Cut
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Pedal
ID 22
Program Name Soft E Piano Pad
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LoPass Freq Cut
Slider D Tremolo Rate
SW1 Octave Shift
SW2 Layer Enable (Pad)
SW4 Arp On/Off
SW5 Disable Chorus Layer
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
CCPed2 Timbre
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Pedal
FtSw4 ArpLatch
ID 23
Program Name Hybrid E Piano
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Tremolo Rate
SW1 Octave Shift
SW2 Disable Thump
SW4 Arp On/Off
SW5 Impact
MW Tremolo Depth
Breath/CCPed2 Timbre
Ribbon Pitch Bend
CCPed1 Expression
CCPed2 Timbre
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Pedal
ID 24
Program Name CM Wurly 2g
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Tremolo Rate
SW1 Octave Shift
SW2 Disable Thump
SW4 Arp On/Off
SW5 Impact/Thump Lvl
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
CCPed2 Timbre
FtSw1 Sustain
FtSw2 Sostenuto
