PC2 Programs and Controller Assignments
Programs and Controllers
C-13
ID 83
Program Name Slo Wood Flute
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Breath Noise
Slider D Chiff Noise
SW1 Octave Shift
SW4 Arp On/Off
SW5 "Layer Enable (""ooh"")"
MW Tremelo Depth (Cut)
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
ID 84
Program Name DIG DAT DOW
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LowPass Freq
Slider D LoPass Resonance
SW1 Octave Shift
SW2 Release Control
SW3 Layer Delay
SW4 Arp On/Off
SW5 Octave Layer Enable
MW Vibrato Depth
Mpress Vibrato Rate
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 85
Program Name 1/3 Pulse Bass
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LowPass Freq
Slider D LoPass Resonance
SW1 Octave Shift
SW2 Release Control
SW3 Impact
SW4 Arp On/Off
SW5 Octave Layer Enable
MW "Vibrato Rate, Depth"
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 86
Program Name Porky Bass
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LowPass Freq
Slider D LoPass Resonance
SW1 Octave Shift
SW2 Release Control
SW3 Octave Layer Enable
SW4 Arp On/Off
SW5 Stereo Layer Enable
MW Vibrato Depth
Mpress Vibrato Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 87
Program Name Deep HooHoo Bass
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LowPass Freq
Slider D LoPass Resonance
SW1 Octave Shift
SW2 Release Control
SW3 Impact
SW4 Arp On/Off
SW5 Octave Divide
MW "Vibrato Rate, Depth"
Mpress "Vibrato Rate, Depth"
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 88
Program Name Rez Aah
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LoPass Freq
Slider D LoPass LFO Rate
SW1 Octave Shift
SW2 Release Control
SW4 Arp On/Off
SW5 Timbre (Envelope)
MW Vibrato
Mpress Swell (Layer 3)
Breath/CCPed2 Swell (Layer 3)
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
