Kurzweil PC2 [132/170] Kb3 controllers
![Kurzweil PC2 [132/170] Kb3 controllers](/views2/2008899/page132/bg84.png)
B-10
Reference
KB3 Controllers
KB3 Controllers
ThereÕs a subset of the MIDI Controller numbers dedicated to controlling KB3 features. The Þrst
column in the following table lists the Controller numbers that KB3 programs always respond
to. KB3 programs also respond to the Controller numbers in the second column; these are the
Controller numbers that the Voceª MIDI Drawbar Controller uses to control common tone-
wheel organ features. Whatever kind of external MIDI source youÕre using, you can use the
MIDI controller numbers in either the second or third column to control the corresponding KB3
feature in the Þrst column. For example, to control Drawbar 1, you can send either MIDI 6 or
MIDI 12.
KB3 Program Feature
MIDI Controller Number
K2600 Voce
Drawbar1 6 12
Drawbar2 22 13
Drawbar3 23 14
Drawbar4 24 15
Drawbar5 25 16
Drawbar6 26 17
Drawbar7 27 18
Drawbar8 28 19
Drawbar9 1 20
Expression Pedal 4 8
Percussion On/Off 73 N.A.
Percussion High/Low 72 72
Percussion Loud/Soft 71 71
Percussion Fast/Slow 70 70
Rotating Speaker Slow/Fast 68 68
Vibrato/Chorus On/Off 95 95
Vibrato/Chorus Selector 93 93
Key Click Level 89 89
Leakage Level 90 90
