![Kurzweil PC2 [128/170] Parameter reference](/views2/2008899/page128/bg80.png)
B-6
Reference
Parameter Reference
Global
Local Control Off, On On
Clock Internal, External Internal
Transmit Clock Off, On, Seq Seq
Touch 1 Linear, 2 Light1, 3 Light2, 4 Light3, 5 Hard1, 6 Hard2, 7 Hard3 1 Linear
Chg Setups Keys Up, Immed Keys Up
Setup Chg Chan None, 1–16 None
MIDI In Normal, Remap, Merge Normal
Wrap/Skip Off, On On
Exit Save Never, Ask Never
Drum Remap Normal, PC2ReMap, GMReMap Normal
KB3 MIDI Chan 1–16 1
Tuning -100 ct to 100 ct 0 ct
Recv Trans -64 to 63 0
Bank Sel Ctl 0, 32, 0/32, 0 or 32 0/32
All Notes Off Respond, Ignore Respond
Device ID 0–127 0
Xmit Buttons Off, On Off
Output Mode Stereo, Mono Stereo
DigOut Mode Pro, Cons Pro
DigOut ChanStat Off, On On
DigOut Width 16 bit, 18 bit, 20 bit, 24 bit 16 bit
DigOut Level Slider, Off, -79dB to +24 dB Slider
DigOut Shaping Off, On On
Mem Avail Not editable 220K
Keyboard Not editable 76 Ver: 1
Expansion
Blocks
EXP1 Not editable No
EXP2 Not editable No
Reset PC2? N/A N/A
Dump all objects? N/A N/A
MIDIScope? N/A N/A
MIDI Recv (for
each channel)
(Channel status) Off, On On
Bank:Program 0:000–16,384:127 0:000
Volume 0–127 127
Pan 0–127 64
Wet/Dry Mix
Global A>B 0%–100% Varies
A: 0%–100% Varies
B: 0%–100% Varies
Effects (for A
and B outputs)
(Status) On / Off Varies
Select 1–380 (nonconsecutive) N/A
Parameter 1 Determined by the FXMod assignment the current effect Varies
Parameter 2 Determined by the FXMod assignment the current effect Varies
Parameter 3 Determined by the FXMod assignment the current effect Varies
Parameter 4 Determined by the FXMod assignment the current effect Varies
Wet/Dry
Global A>B 0%–100% Varies
A: 0%–100% Varies
B: 0%–100% Varies
FX Mode
FX Chg Mode Panel, Auto Auto
FX Channel Current, 1–16 Current
Stored FX Factory, User User
Parameter
Group
Subgroup
(if any)
Parameter Range of Values Default
