B-2
Reference
Specifications
Environmental Specifications
Audio Specifications
Line-Level Left and Right Analog Audio Outputs
Digital Audio Output
Headphone Output
Minimum Maximum
Operating temperature 40 F 5 C 104 F 40 C
Storage temperature -13 F -25 C 185 F 85 C
Operating humidity 5% 95% (non-condensing)
Storage humidity 5% 95% (non-condensing)
Connectors
Balanced outputs using two 1/4-inch stereo (tip-ring-sleeve) phone plugs and shielded twisted-
pair cable or unbalanced using two 1/4-inch mono (tip-ring) phone plugs and coaxial cable
Impedance
400 Ω, balanced, nominal
200 Ω, unbalanced, nominal
Maximum output level
21 dBu (8.7 Volts RMS) balanced, high-impedance load
15 dBu (4.4 Volts RMS) unbalanced, high-impedance load
Frequency response 20Hz–20kHz +/– 0.6 dB
Idle channel noise Less than -115 dBA, balanced, relative to full-scale signal
Dynamic range Greater than 112 dBA, balanced, using -60 dBFS signal
Stereo channel separation 96 dB
Connectors IEC 60958-3 (S/PDIF) electrical interface using one RCA connector
Output impedance 75 Ω, nominal
Formats S/PDIF (Consumer) and AES/EBU (Professional)
Digital audio format 48 kHz linear PCM
Bit width 16, 18, 20, and 24 bits (software selectable)
Dither Flat and shaped (software selectable)
Output impedance 47 Ω, nominal
Maximum output level -4 dBu (0.5 Volts RMS) with 32 Ω load
