Kurzweil PC2 [144/170] Pc2 programs and controller assignments
![Kurzweil PC2 [144/170] Pc2 programs and controller assignments](/views2/2008899/page144/bg90.png)
C-2
PC2 Programs and Controller Assignments
Programs and Controllers
ID 5
Program Name ClassicalGrand 2
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider D Vibrato Rate
SW1 Octave Shift
SW4 Arp On/Off
SW5 Enable Vibrato
MW Vibrato Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 soft ped
ID 6
Program Name Mono Grand Piano
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider D Vibrato Rate
SW1 Octave Shift
SW4 Arp On/Off
SW5 Enable Vibrato
MW Vibrato Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 soft ped
ID 7
Program Name Piano for layers
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider D Vibrato Rate
SW1 Octave Shift
SW4 Arp On/Off
SW5 Enable Vibrato
MW Vibrato Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 soft ped
ID 8
Program Name Stereo Rock Pno
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider D Vibrato Rate
SW1 Octave Shift
SW4 Arp On/Off
SW5 Enable Vibrato
MW Vibrato Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 soft ped
ID 9
Program Name Rock Grand
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider D Vibrato Rate
SW1 Octave Shift
SW4 Arp On/Off
SW5 Enable Vibrato
MW Vibrato Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 soft ped
ID 10
Program Name Sustain Grand440
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider D Vibrato Rate
SW1 Octave Shift
SW4 Arp On/Off
SW5 Enable Vibrato
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 soft ped
ID 11
Program Name Mono Stage Piano
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider D Vibrato Rate
SW1 Octave Shift
SW4 Arp On/Off
SW5 Enable Vibrato
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 soft ped
ID 12
Program Name Dyn Stage Piano
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider D Vibrato Rate
SW1 Octave Shift
SW4 Arp On/Off
SW5 Enable Vibrato
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 soft ped
