PC2 Programs and Controller Assignments
Programs and Controllers
C-15
ID 95
Program Name La Grande Jatte
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LoPass Freq
Slider D LoPass Resonance
SW1 Octave Shift
SW2 Release Control
SW3 Layer Switch
SW4 Arp On/Off
SW5 Attack Control
MW Vibrato/Trem
Mpress Vibrato/Trem
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
ID 96
Program Name Acoustic Guitar
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C EQ Ctr Freq
Slider D EQ Cut/Boost
SW1 Octave Shift
SW2 Envelope Control
SW4 Arp On/Off
SW5 Sample Start
MW Vibrato
Mpress Vibrato Rate
Breath/CCPed2 Vibrato
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
ID 97
Program Name Strummer 12 Str
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Brightness
Slider D Vibrato Rate
SW1 Octave Shift
SW2 Envelope Control
SW4 Arp On/Off
SW5 Layer Detune
MW Vibrato
Breath/CCPed2 Vibrato
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
ID 98
Program Name Rich 6 Str Gtr
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Vibrato Rate
SW1 Octave Shift
SW2 Envelope Control
SW4 Arp On/Off
SW5 Stereo Image
MW Vibrato
Breath/CCPed2 Vibrato
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
ID 99
Program Name Ol' 12 Str Gtr
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C EQ Ctr Freq
Slider D EQ Cut/Boost
SW1 Octave Shift
SW2 Envelope Control
SW4 Arp On/Off
SW5 Layer Detune
MW Vibrato
Mpress Vibrato Rate
Breath/CCPed2 Vibrato
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
ID 100
Program Name Chorus Elec Gtr
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Tremolo Rate
SW1 Octave Shift
SW2 Envelope Control
SW4 Arp On/Off
SW5 Disable Layer Detune
MW Tremolo Depth
Breath/CCPed2 LFO2 Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Ped
