Kurzweil PC2 [148/170] Pc2 programs and controller assignments
![Kurzweil PC2 [148/170] Pc2 programs and controller assignments](/views2/2008899/page148/bg94.png)
C-6
PC2 Programs and Controller Assignments
Programs and Controllers
ID 31
Program Name Rich Digital EP
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Tremelo Rate
SW1 Octave Shift
SW2 Envelope Ctl
SW4 Arp On/Off
SW5 Disable Layer
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
CCPed2 Timbre
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Pedal
ID 32
Program Name C3PO
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Tremolo Rate
SW1 Octave Shift
SW2 Sample Start
SW4 Arp On/Off
SW5 Enable Layer
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 33
Program Name Digi E Grand
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Tremolo Rate
SW1 Octave Shift
SW2 Attack Control
SW4 Arp On/Off
SW5 Disable Layer
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 34
Program Name Electric Grand
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Tremolo Rate
SW1 Octave Shift
SW2 Attack Control
SW4 Arp On/Off
SW5 Disable Layer
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 35
Program Name FantAsmAtron
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Tremolo Rate
SW1 Octave Shift
SW2 Attack Control
SW4 Arp On/Off
SW5 Disable Layer
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 36
Program Name AtmAz
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Attack Ctrl
SW1 Octave Shift
SW2 Release Control
SW4 Arp On/Off
SW5 Switch Layers
MW Vibrato Rate
Mpress Vibrato Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
