![Kurzweil PC2 [127/170] Parameter reference](/views2/2008899/page127/bg7f.png)
Reference
Parameter Reference
B-5
Internal Voices:
Timbre (for each
layer)
KeyMap L Any keymap
Keymap R Any keymap
Key Range
Lo C -1 to G 9 C 0
Hi C -1 to G 9 C 8
Block param 1 Varies according to Block
Block Param 2 Varies according to Block
Amp -96dB to 48dB 20 dB
Mod Wheel None, 0–127 0
Breath None, 0–127 0
Data None, 0–127 0
MIDI 9 None, 0–127 0
MIDI 12 None, 0–127 0
MIDI 13 None, 0–127 0
MIDI 29 None, 0–127 0
Internal Voices:
Envelope
Attack 0.018x–50.000x 1.000x
Decay 0.018x–50.000x 1.000x
Release 0.018x–50.000x 1.000x
Internal Voices:
LFO
LFO1 Rate 0.00Hz–24.00Hz 2.00Hz
LFO1 Shape
None, 1/4 /Sine, 1/2 /Sine, 3/4 Sine, Sine, 1/4 +Sine, 1/2 +Sine,
3/4 +Sine, +Sine, 1/4 Squ, 1/2 Squ, 3/4 Squ, Square, 1/4 +Squ,
1/2 +Squ, 3/4 +Squ, +Square, 1/4 Tri, 1/2 Tri, 3/4 Tri, Triangle,
1/4 +Tri, 1/2 +Tri, 3/4 +Tri, +Triangle, Rise Saw, +Rise Saw,
Fall Saw, +Fall Saw, 3 Step, +3 Step, 4 Step, +4 Step, 5 Step,
+5 Step, 6 Step, +6 Step, 7 Step, +7 Step, 8 Step, +8 Step,
10 Step, +10 Step, 12 Step, +12 Step
None
GLFO Rate 0.00Hz–24.000Hz 2.00Hz
GLFO Shape Same as LFO None
Parameter
Group
Subgroup
(if any)
Parameter Range of Values Default
